Accessories for profiles 90° for 200 mm bracket
The brackets are used for corner and T-joints of I and U profiles, where they are subjected to tensile and compressive forces, bending moment and shear.
The brackets are designed for efficient assembly and load transmission. The brackets can transmit a greater shear force than the profile. This simplifies the sizing of the assembly.
Material: The brackets are made of acid-resistant stainless steel (1.4404 / AISI 316L) and are delivered pickled for maximum durability.
Number of holes: 8. The holes are over-dimensioned by 1.0 mm in relation to the bolt.
The brackets fit the profile heights 200 mm
Items in stock: 15
4-10 days
Description
Description
The brackets are used for corner and T-joints of I and U profiles, where they are subjected to tensile and compressive forces, bending moment and shear.
The brackets are designed for efficient assembly and load transmission. The brackets can transmit a greater shear force than the profile. This simplifies the sizing of the assembly.
Material: The brackets are made of acid-resistant stainless steel (1.4404 / AISI 316L) and are delivered pickled for maximum durability.
Number of holes: 8. The holes are over-dimensioned by 1.0 mm in relation to the bolt.
The brackets fit the profile heights 200 mm
